D4MC-1000 Small Lever Limit Switch

D4MC-1000 Small Lever Limit Switch – High Precision Enclosed Micro Switch

The D4MC-1000 Small Lever Limit Switch is an economical, high-utility enclosed limit switch designed for reliable position sensing, automated machine control, and safety interlocking across various industrial applications. Built with a high-rigidity structure and integrated basic micro switch, the D4MC-1000 delivers exceptional repetitive accuracy and long operational life under demanding working conditions.

Featuring a stainless steel straight hinge lever actuator, this limit switch detects physical movement and positions with minimal required operating force. Its rugged outer housing is molded from high-intensity, splash-proof plastic that resists oil, water, and mechanical dust, making it ideal for tough manufacturing and industrial settings.

Key Features & Benefits

• High Precision Actuation: Equipped with a durable stainless steel straight hinge lever for accurate limit detection and smooth mechanism triggering.

• Oil-Proof & Water-Resistant Design: Robust protective housing safeguards internal contacts against liquid splashes, ambient moisture, and dust contamination.

• Standard Contact Configuration: Features a standard 1NO + 1NC (SPDT) snap-action contact structure suitable for control and safety circuit operations.

• High Electrical Capacity: Supports up to 250V AC and 10A, allowing seamless integration into standard AC power control circuits.

• Compact & Easy Mounting: Designed with standard mounting dimensions and accessible terminal screws for quick wire installation and maintenance.

• D4MC-1000 Small Lever Limit Switch
• Delivery available all over Pakistan
• Discount available on bulk order
• Economical, high utility enclosed switch
• Enclosed switches with built-in basic switches.
• Various of actuators, the operation position is adjustable
• Outer shell covered with intensive plastic, water-proof and oil-proof.

• Mechanical & Operating Characteristics

  • Actuator Type: Straight Hinge Lever (Stainless Steel)

  • Operating Force (OF): Maximum 1.67 N (approx. 170 gf)

  • Release Force (RF): Minimum 0.25 N (approx. 25 gf)

  • Movement Differential (MD): Maximum 3.0 mm

  • Overtravel (OT): Minimum 4.0 mm

  • Operating Position (OP): 25mm
