Description

Specification

• Dimensions:about48mm48mm110mm(APP)
• Measuring accuracy: 0.5%FS
• Cold-end compensation tolerance: 2 Celsius (can be modified by software in 0~50 Celsius )
• Resolution: 14 bit
• Sampling cycle: 0.5 Sec
• Process value (PV), Setting value (SV)
• Output, alarm and self-tuning can be indicated by: LED
• PIN control (including ON/OFF, step-type PID and continuous PID)
• Self-tuning control
• Relay output: contact capacity 250V AC 3A (resistive load)
• Alarm function output: 2 way
• Contact capacity of output: 250V AC 3A (resistive load)
• Setting value (SV): identical to measuring range (PV)
• Proportional band (P): 0~full range (ON/OFF control when set to 0)
• Detective temperature range:0 to 400 Celsius
• Insulation resistance: >50M ohm(500V DC)
• Insulation resistance: 1500V AC/min
• Power Consumption: 10 VA
• Service environment: 0~50 Celsius ,
• environment with no corrosive gas 30~85% RH
